AZ Window Services Solar Gard Window Tint
Solar Gard exterior grade solar control films are designed to reduce heat, glare, and harmful UV rays while improving the comfort and efficiency of your space. Professionally installed by AZ Window Services, these high-performance films help keep interiors cooler, protect furnishings from fading, and enhance the overall performance of your windows.
Panorama Hilite
Hilite is Solar Gard’s flagship product line – blocking 55% of the total solar energy while barely visible to the naked eye.
Key Benefits
- Industry leading ‘spectral selectivity’ keeps the heat out while letting the light’
- Less visibly reflective than clear glass -providing superior optical clarity
- High heat rejection results in improved indoor comfort
- UV blockers protect people and property from damaging UV rays
| Specification | Hilite 25 | Hilite 40 | Hilite 55 | Hilite 70 |
|---|---|---|---|---|
| Visible light transmittance % | 21% | 40% | 56% | 70% |
| Visible light reflectance (exterior) % | 5% | 6% | 7% | 8% |
| Visible light reflectance (interior) % | 5% | 6% | 7% | 8% |
| Solar heat gain coefficient | 0.35 | 0.39 | 0.44 | 0.46 |
| Total solar energy rejected % | 65% | 61% | 56% | 54% |
| UV Tdw-ISO @ 300 to 700 nm % | 14% | 26% | 38% | 44% |
| UV light blocked (300 to 380 nm) % | >99% | >99% | >99% | >99% |
| Fade Reduction % | 83% | 68% | 54% | 46% |
Performance Notes:
- Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes.
- This data is provided for informational purposes only and are subject to normal manufacturing variances.
- Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.
CSI Specifications: Solar Control Films 08 87 13
